Ebb & flow rolling benches (also known as rolling ebb & flood benches, rolling sub irrigation benches, and rolling flood benches) have been in use in greenhouses for at least 90 years. Our polystyrene benchtops feature drainage channels that serve multiple purposes. They allow water to flow evenly during flooding, ensuring all plants on the bench are watered simultaneously. After irrigation, the bench drains evenly through the grooves, preventing plants from sitting in standing water. Our Ebb & Flow benches are ideal for horticulture, including cannabis cultivation. They are made with high-quality materials such as galvanized steel tubing for legs and framework, marine-grade aluminum for side and end rails, and custom extruded aluminum for rounded bench corners. The benchtops are vacuum-formed UV resistant polystyrene, manufactured in long lengths to minimize glue joints and facilitate easy shipment.
ADVANTAGES OF GROWING ON EBB & FLOW ROLLING BENCHES
At Innovative Growers Equipment we stand behind all our products that we manufacture, sell and install for our customers. We follow very strict quality control guidelines we have set to ensure the customer gets an outstanding product each time.
*When used as a flood and drain table.
Ebb & Flow Rolling Benches
All sizes of Ebb and Flow benches from Innovative Growers Equipment can be furnished as rolling benches. Rolling benches are commonly used where maximum efficiency in the use of production space is desired, and good access to all the crop areas by personnel and equipment is required. Some degree of access to the crops is given up in exchange for greater efficiency of production.
Standard Ebb Benches Vs Max Roll Benches
Standard rolling benches are the same price as the same size stationary benches. Max roll benches are to be installed on concrete floors, as some of the legs are required to be attached to the floor with anchors to prevent tipping. Standard roll benches are not required to be anchored to the floor.
Complete Max Roll Benches
- Bench structure galvanized 1” steel tubing
- Leveling header – 1¼” galvanized tubing, with 2” of leveling capability
- Anti-tip bracket welded together with galvanized steel tubing
- Metal brackets to secure the bench to concrete
- Extruded Aluminum side rails, rounded bench corners
- Molded polystyrene Ebb and Flow tray inserts
- Bench connector barbed through one end to connect to ¾” hose
- All necessary glue and fasteners for assembly
- All parts pre-drilled, pre-punched, pre-cut, and ready to assemble
Ebb & Flow Rolling Bench Specifications
All our benches are made to order for each customer. Ebb & flow rolling benches are available in many widths. We currently stock 13’, 2’, 3’, 4’, 4.5’, 5’, 5.5’, & 6’ wide trays at our manufacturing warehouse. Many other widths are available as a special order. The bench lengths are completely custom, but generally must be at least 7½ feet long as a minimum. Depending on our backlog of orders, we are usually able to ship orders of our stocked widths in about 6-8 weeks. Other special widths may have longer lead times. View the chart for rolling distances.
|Bench Size||Standard Roll||Max Roll|
Ebb & Flow Trays
In addition to our signature Ebb and flow rolling benches, we also sell the Ebb and Flow trays separately. These can be used as replacement trays in existing Ebb and Flow benches, or to convert other existing benches into modern Ebb and Flow sub-irrigation benches. If you wish to convert existing benches into Ebb and Flow benches, the following are some considerations to keep in mind:
- The bench/bench framework must be able to support the Ebb and Flow trays either completely or with sturdy cross bars spaced no more than 50cm (19 1/2’) apart on center.
- The existing bench framework must be sturdy and stable, able to support the benchtop, the plants, as well as the water when irrigating (about an additional 4 pounds per square foot).
- The bench must be able to be leveled. Ebb and Flow trays must be completely level to function correctly. Ideally, there is a method to adjust the benchtop level at frequent locations (typically at each leg).
- You will need to have access to the plumbing well at the end of the bench tray to connect the plumbing to the underside of the benchtop.
Expanded Metal Benches
We offer a line of expanded metal benches manufactured with the same quality materials as our signature Ebb & Flow benches. Our benches with expanded metal tops are nearly identical to our Ebb & Flow benches—they have expanded metal benchtops in place of Ebb & Flow trays.
Many customers like to have some of their benches with expanded metal tops, typically in retail areas. Our expanded metal benches have the same legs, framework, extruded aluminum side rails, and rounded corners as our Ebb & Flow benches. This allows for a cohesive appearance in areas with both bench types.
The aluminum side rails extend approximately three inches above the expanded metal benchtops. This helps keep plants from being knocked off of the benches. The aluminum side rails and the expanded metal tops are hot-dip galvanized after being formed, which results in a durable bench that will retain its clean, like-new appearance for many years.
